IMPORTANT DATA
• Saw blade diameter - 254 mm
• Mitre setting - 52 ° L / 62 ° R
• Incline setting - 47 ° L

Part no. 0601B20541 (110V version) 0601B20542 (240V version)

Large cutting capacity and highest precision
• Powerful 1800 W motor for the hardest of jobs
• Precise cuts due to parallel guidance of the slide function
• Up to 305 mm max. cutting width
• 87 mm max. cutting height for a wide variety of applications
• 52° left / 62° right mitre angle for various angle cuts
• Spindle lock for easy saw blade changes
• Swivelling saw head for bevel cuts up to 47° on the left
• Table and stop made of high-quality die-cast aluminium

COMPLETE WITH
• Dust bag - 2 605 411 204
• Dust extraction adapter - 2 600 499 071
• Insert plate - 2 607 960 019
• Quick-action clamp - 2 608 040 205
• Saw blade 254 x 30 mm - 2 608 640 436

TECHNICAL DATA
• Cutting capacity, 0° - 87 x 305 mm
• Cutting capacity, 45° mitre - 87 x 216 mm
• Cutting capacity, 45° incline - 53 x 305 mm
• Mitre setting - 52 ° L / 62 ° R
• Incline setting - 47 ° L
• Depth x length x height - 78 x 68 x 54 cm
• No-load speed - 4.700 rpm
• Saw blade diameter - 254 mm
• Saw blade bore - 30 mm
• Weight - 21,5 kg
• Rated power input - 1.800 W
• Linked products - System accessories-AC categories - 172481

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745
The A-rated noise level of the power tool is typically as follows: Sound pressure level 98 dB(A); Sound power level 109 dB(A). Uncertainty K= 3 dB.


PLEASE STIPULATE ON ORDER IF YOU REQUIRE 240V OR 110V MACHINE
