IMPORTANT DATA
• Saw blade diameter - 305 mm
• Mitre setting - 52 ° L / 60 ° R
• Incline setting - 47 ° L / 47 ° R

Part no. 0601B23541 (110V version) 0601B23542 (240V version)

High cutting capacity and high level of comfort
• Bevel setting on both sides up to 47°
• Easy, convenient angle setting on the front of the machine (52° left, 60° right)
• Handle with softgrip can be locked conveniently in 4 positions
• High cutting capacity of 110 x 305 mm (0° mitre, 0° incline)

COMPLETE WITH
• Dust bag with adapter - 2 605 411 211
• Insert plate - 2 607 960 020
• Quick-action clamp - 2 608 040 205
• Saw blade 305 x 30 mm - 2 608 640 441

TECHNICAL DATA
• Cutting capacity, 0° - 110 x 305 mm
• Cutting capacity, 45° mitre - 110 x 217 mm
• Cutting capacity, 45° incline - 63 x 305 mm
• Mitre setting - 52 ° L / 60 ° R
• Incline setting - 47 ° L / 47 ° R
• Depth x length x height - 89 x 69 x 75 cm
• No-load speed - 3.800 rpm
• Saw blade diameter - 305 mm
• Saw blade bore - 30 mm
• Weight - 29,1 kg
• Rated power input - 1.800 W
• Linked products - System accessories-AC categories - 172481

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745

The A-rated noise level of the power tool is typically as follows: Sound pressure level 89,5 dB(A); Sound power level 102,6 dB(A). Uncertainty K= 3 dB.


PLEASE STIPULATE ON ORDER IF YOU REQUIRE 240V OR 110V MACHINE
