Bosch developed the first jigsaw – and has since reinvented it over and over again. Regardless of whether you need a tool for precise sawing at accurate angles or for robust use: Bosch offers professionals the right jigsaw for every application.

IMPORTANT DATA
• Rated power input - 780 W
• Cutting depth in wood - 150 mm
• Cutting depth in aluminium - 20 mm

Part no. 0601512060 (110V version) 0601512070 (240V version)

The most powerful tool in its price class
• High power reserves, even in hard and thick beams, due to powerful and overload-capable 780-watt motor
• Extremely robust and bend-resistant sole plate for the toughest jobs
• High cutting precision due to new saw blade clamping system
• Tool-free saw blade clamping system for easy and fast saw blade changes
• Ergonomic grip area with softgrip surfaces for a high level of work comfort
• 4-stage pendulum action for fine through to coarse cuts
• Electronic speed preselection

COMPLETE WITH
• 1 saw blade T 144 DP (ET no. 2 609 991 569)
• Anti-splinter guard - 2 601 016 096
• Dust extraction set - 2 605 510 294
• Glide shoe (ET no. 2 601 099 183)
• Hood (ET no. 2 605 510 293)
• Suction nozzle (ET no. 2 605 730 055)

TECHNICAL DATA
• Rated power input - 780 W
• No-load stroke rate - 500 – 3.100 spm
• Weight - 2,6 kg
• Cable length - 4 m
• Stroke height - 26 mm
• Cutting depth in wood - 150 mm
• Cutting depth in aluminium - 20 mm
• Cutting depth in non-alloyed steel - 10 mm

FUNCTIONS
• Pendulum stroke adjustment
• Dust extraction
• Bosch SDS System
• Electronic
• Constant Electronic

NOISE/VIBRATION INFORMATION
Measured values determined according to EN 60745
Total vibration values (vector sum of three directions)
Sawing sheet metal
• Uncertainty K - 1.5 m/sē
Sawing wood
• Uncertainty K - 1.5 m/sē


PLEASE STIPULATE ON ORDER IF YOU REQUIRE 240V OR 110V MACHINE
